Description
- Motor System: Adopt industrial-grade turbine motor, strong suction, good heat dissipation, can work continuously for a long time, durable and long life. The motor is silencing and has low noise.
- Protection Device: Equipped with motor protector, overload, phase loss leakage protection device, and electrostatic chain. Equipped with negative pressure gauge, real-time monitoring of motor negative pressure, excellent protection for operators and machines.
- Filter System: The filter system is an important part of industrial vacuum cleaners and a decisive factor for the long-lasting suction and clean discharge of vacuum cleaners.
The back-blowing industrial vacuum cleaner adopts Japanese Toray filter material, with a filtration level of 0.3 microns and a pleated star-shaped design. The filtration area is larger, reaching 35,000 cm2, which is 3 times that of ordinary filters with the same diameter, thus providing better air permeability. - Manual Back-blowing Function: Manual back-blowing device, which can effectively prevent filter clogging. The manual back-blowing device is installed on the top of the machine. The manual back-blowing device can effectively clean the dust and debris on the outer layer of the filter, prevent the filter from being blocked due to long-term operation of the machine, and keep the suction power lasting. There is no need to turn off the vacuum motor switch. Press the hand-pressed back-blowing handle and the air will blow the dust out of the filter in the opposite direction.
- Dust Collection Unit: The barrel body and dust barrel are made of stainless steel with a capacity of 70L. The collection barrel is detachable with wheels and handles. Just pull the handle lightly to separate and move it independently, making it easy to clean the garbage in the barrel.
- Vacuum Cleaner Accessories: Standard vacuum accessories: S-bend pipe, vacuum head, flat nozzle, round brush, 5-meter EVA vacuum hose. It has a larger working area and a wider vacuuming area than traditional vacuum cleaner accessories, and can quickly clean dust, iron filings and other materials that need to be sucked.
Parameter
| Type | Units | CY70SC/2.2 | CY70SC/3 | CY70SC/4 |
| Volts | V/Hz | 380V/50 | 380V/50 | 380V/50 |
| Power | KW | 2.2 | 3.0 | 4.0 |
| Vacuum | Kpa | 24 | 26 | 29 |
| Airflow | M³/h | 320 | 320 | 380 |
| Filter | c㎡ | 35000 | 35000 | 35000 |
| Noise | Db(a) | 68 | 69 | 71 |
| Suctiner | mm | 40 | 40 | 40 |
| Volume | L | 70 | 70 | 70 |
| Weight | kg | 80 | 84 | 88 |
| Dimensions | mm | 1000*520*1120 | ||
Main Components
The hand-pressed back-blowing device adopts the airflow back-blowing principle to clean and filter easily, quickly and efficiently!
Application:
FAQ
Q: What types of cleaning equipment do you offer?
A: We offer commercial vacuums, industrial vacuums, wet and dry vacuums, sweepers, and fully automatic floor scrubbers.
Q: What industries are your products suitable for?
A: Our equipment is widely used in factories, hotels, hospitals, docks, petroleum, electricity, railways and other industries.
Q: Can the equipment be customized?
A: Yes, we can professionally customize various cleaning equipment according to the customer’s on-site environment and needs.
Q: How to get after-sales service?
A: We have a dedicated repair center to provide equipment maintenance and after-sales service.
Q: How can I contact you for more information?
A: You can contact us through our website or call our customer service hotline for more information and support.
To enhance customer experience, our equipment’s appearance and performance will be updated periodically.
Please contact us for the latest product specifications and images.
