Description
- The vacuum cleaner host can be equipped with two 12.5-25kw high-pressure fans. When two high-pressure fans are used at the same time, the maximum pressure can reach 50-70kpa;
- The collection device is equipped with a discharge valve (the discharge time can be timed);
- Pulse backwash cleaning and filtering; there is a built-in cyclone separator inside;
- Pressure relief device. When a certain pressure is reached, the pressure relief device automatically opens to protect the motor;
- The built-in main electronic control components (such as inverters, PLCs, touch screens) and turbine motors can realize independent control of the electric box;
- Built-in overload, overtemperature, phase loss, overvoltage and other protections, the control panel is simple and generous, and can be easily controlled; the alarm indication and start-stop buttons on the panel;
- It is required to have a humanized interactive interface and an intelligent control screen; it is designed with multiple visual adjustment functions such as pressure display, temperature display, temperature alarm, pressure alarm, running time, backwash time, etc.
- It can record and export equipment working data (pressure value, temperature value, running time, etc.) and fault alarm information.
- When the temperature reaches the set value or the negative pressure reaches the set value, it will automatically stop after 30 seconds.
- The touch screen can switch between manual and automatic, which is convenient for later maintenance.
This equipment can be equipped with: high-pressure blower, Roots blower, multi-stage centrifugal blower according to requirements.
Parameter
| Type | Units | CYJY/12.5 | CYJY/15 | CYJY/18.5 | CYJY/20 | CYJY/25 |
| Motor Type | High pressure blower | High pressure blower | High pressure blower | High pressure blower | High pressure blower | |
| Max pipe distance | M | 50M | 60M | 65M | 70M | 75M |
| Volts | V/Hz | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 |
| Power | Kw | 12.5*2 | 15.0*2 | 18.5*2 | 20*2 | 25*2 |
| Vacuum | Kpa | 34 | 38 | 42 | 48 | 52 |
| Airflow | M³/h | 1050*2 | 1050*2 | 1050*2 | 1350*2 | 1350*2 |
| Filter | c㎡ | 16.8 | 16.8 | 16.8 | 16.8 | 16.8 |
| Noise | dB(A) | 74 | 74 | 74 | 74 | 72 |
| Suctiner | mm | 40-100 | 40-100 | 40-100 | 40-100 | 40-100 |
| Volume | L | 800*2 | 800*2 | 800*2 | 800*2 | 800*2 |
| Weight | kg | 600 | 600 | 600 | 600 | 600 |
| Discharging Method | Pneumatic butterfly valve | Pneumatic butterfly valve | Pneumatic butterfly valve | Pneumatic butterfly valve | Pneumatic butterfly valve | Pneumatic butterfly valve |
| Dimensions | mm | 2600*1160*2950 mm | ||||
Features
- High-Pressure Fan Configuration: The vacuum cleaner can be equipped with two 12.5-25 kW high-pressure fans, achieving a maximum pressure of 50-70 kPa when both are in use.
- Efficient Discharge System: The collection device features a discharge valve with customizable timing for effective material unloading.
- Advanced Filtration System: Includes pulse backwash cleaning, filtering, and a built-in cyclone separator to enhance filtration efficiency.
- Automatic Pressure Relief: Equipped with a pressure relief device that automatically activates to protect the motor when a specific pressure threshold is reached.
- Intelligent Control Interface: Features a user-friendly touch screen with functions for pressure and temperature display, alarms, and the ability to record and export operational data, supporting both manual and automatic operation for easy maintenance.
FAQ
Q: What types of cleaning equipment do you offer?
A: We offer commercial vacuums, industrial vacuums, wet and dry vacuums, sweepers, and fully automatic floor scrubbers.
Q: What industries are your products suitable for?
A: Our equipment is widely used in factories, hotels, hospitals, docks, petroleum, electricity, railways and other industries.
Q: Can the equipment be customized?
A: Yes, we can professionally customize various cleaning equipment according to the customer’s on-site environment and needs.
Q: How to get after-sales service?
A: We have a dedicated repair center to provide equipment maintenance and after-sales service.
Q: How can I contact you for more information?
A: You can contact us through our website or call our customer service hotline for more information and support.
To enhance customer experience, our equipment’s appearance and performance will be updated periodically.
Please contact us for the latest product specifications and images.
